The ZV-420C packaging machine is suitable for packaging soya chunks in different bag types.
Packaging Range: 100 grams - 1000 grams.
Machine type:
ZV-420CPackaging speed:
5-60bag/MinutesPackaging size:
L:80-300mm W:60-200mmMachine size:
L:1217*W:1015*H:1343(mm)Machine material:
304 stainless steel
Specifications:
|
Model |
ZV-420 |
ZV-520 |
ZV-620 |
ZV-720 |
|
Film Width |
Max.420mm |
Max.520mm |
Max.620mm |
Max.720mm |
|
Bag Length |
80-300mm |
80-350mm |
100-450mm |
100-500mm |
|
Bag Width |
60-200mm |
100-250mm |
65-300mm |
180-350mm |
|
Roll Diameter |
Max.320mm |
Max.320mm |
Max.320mm |
Max.320mm |
|
Film Thickness |
0.04-0.12mm |
0.04-0.12mm |
0.04-0.12mm |
0.04-0.12mm |
|
Measuring Range |
150-1500ml |
2000ml |
3000ml |
4000ml |
|
Packing Speed |
5-60bag/min |
5-60bag/min |
5-55bag/min |
5-50bag/min |
|
Power Supply |
220V 50/60Hz 2KW |
220V 50/60Hz 3KW |
220V 50/60Hz 3.2KW |
220V 50/60Hz 3.5KW |
|
Machine Weight |
About 650kg |
About 680kg |
About 700kg |
About 750kg |
|
Option Device |
Two synchronous belt device, air filling device, angle fold device, automatic rectifying device, hole-punching device, link bag device.
|
|||
Applications:
This model is suitable for automatic packaging of rice in plastic bag type, the package range is up to 1kg.
Features:
Option:
1. Date Coder
2. Hole Punching Device(Pinhole, Round hole, the butterfly hole)
3. Linking bag control device
4. Air-filling Device
5. Air Exhaust Device
6. Tear Notch Device
7. Nitrogen inflation device
8. Gusset Bag

Our factory:
Including vertical machine workshop, flow machine workshop, raw material parts warehouse, machine parts production room, office.
